capacity

315kW

400kW

500kW

630kW

800kW

enter

Rated voltage

380V (AC)

acceptable voltage range

> 370V (AC)

frequency

50Hz/60Hz ± 10%

output

frequency

50Hz/60Hz ± 1%

Rated output voltage

380V (AC)

Output voltage regulation

±1%

Technical realization

underlying principle

Apply the principles of electromagnetic balance, electromagnetic induction and electromagnetic compensation

Power saving technology

Adopt dynamic adjustment and stability of three-phase voltage and current, electromagnetic energy storage and flexible compensation adjustment technology, and optimize control strategy through intelligent analysis of big data, so as to improve power quality, reduce power consumption, and achieve comprehensive power saving effect. The specific implementation is as follows: Device data acquisition chip Intelligently sample and analyze the voltage, current and power quality of the external grid, adjust and stabilize the voltage through the internal power processor, and simultaneously reduce the current, reduce the fixed loss and variable loss, so as to achieve the purpose of power saving

power saving algorithm

Electricity consumption = √3×Line voltage×Line current×Power factor×Electricity time saving rate = (Electricity kWh before installation - Electricity kWh after installation) ÷ Electricity kWh before installation × 100%

Power saving effect

Comprehensive power saving rate: 7%~32% has a certain power saving effect on inductive electrical appliances, resistive electrical appliances and capacitive electrical appliances, but its power saving rate for inductive electrical appliances (motors) is the highest, about 15% or more; The power saving rate of resistive electrical appliances (electrical appliances that generate heat and cause sudden changes in current) is about 10% or less, and the power saving rate of capacitive electrical appliances (electrical appliances that convert electrical energy into heat energy and has a high temperature rise) is about 5% or less. .

communication

RS485 remote communication interface

surroundings

Operating temperature

≤80°C

working environment

Keep away from water, fire and other oxidative and fire-prone environments

Working humidity

0~90%

physics

Dimensions: Front (W) X D (D) X H (mm)

900 X 700 X 1600

1200 X 1100 X 1800

1200 X 1100 X 2000

Net weight (kg)

650

700

1000

1200

1400

manage

Remote cloud

Big data cloud monitoring mobile APP terminal, PC terminal, can realize real-time monitoring and scheduling of cloud data

equipment terminal

Integrated display system measurement and control integration can realize real-time data monitoring of equipment

Warranty

Product quality warranty for ten years, free maintenance for one year, and after-sales worry-free service

Serve

If there is any abnormality during the use of the equipment, please contact the manufacturer in time to deal with it
